1. MyBatis 架构概述 #
1.1 什么是 MyBatis #
MyBatis 是一款优秀的半自动化 ORM 框架，它避免了几乎所有的 JDBC 代码和手动设置参数以及获取结果集的工作。
1.2 整体架构图 #
flowchart TB
subgraph Application["应用层"]
A[Mapper Interface]
B[SqlSession API]
end
subgraph Interface["接口层"]
C[SqlSession]
end
subgraph Core["核心处理层"]
D[Configuration]
E[MappedStatement]
F[Executor]
G[StatementHandler]
H[ParameterHandler]
I[ResultSetHandler]
end
subgraph Foundation["基础支撑层"]
J[DataSource]
K[Transaction]
L[Cache]
M[Logging]
N[TypeHandler]
O[Reflection]
end
subgraph DB["数据库层"]
P[(Database)]
end
A --> C
B --> C
C --> F
D --> F
E --> F
F --> G
G --> H
G --> I
H --> N
I --> N
G --> P
F --> L
F --> K
K --> J
J --> P
1.3 三层架构说明 #
flowchart LR
subgraph Layer1["接口层"]
direction TB
S1[SqlSession]
S2["提供API给应用程序调用"]
end
subgraph Layer2["核心处理层"]
direction TB
C1[配置解析]
C2[参数映射]
C3[SQL解析]
C4[SQL执行]
C5[结果映射]
end
subgraph Layer3["基础支撑层"]
direction TB
B1[连接管理]
B2[事务管理]
B3[缓存机制]
B4[类型转换]
end
Layer1 --> Layer2 --> Layer3
2. 核心组件详解 #
2.1 核心组件关系图 #
flowchart TB
subgraph Config["Configuration 全局配置"]
C1[Environment<br/>数据源/事务管理器]
C2[MapperRegistry<br/>Mapper注册表]
C3[MappedStatements<br/>SQL映射]
C4[TypeHandlerRegistry<br/>类型处理器]
C5[TypeAliasRegistry<br/>类型别名]
C6[InterceptorChain<br/>拦截器链]
C7[Cache<br/>缓存配置]
end
Config --> SSF[SqlSessionFactory<br/>创建SqlSession的工厂]
SSF --> SS[SqlSession<br/>执行SQL/获取Mapper/管理事务]
SS --> E[Executor<br/>执行器]
SS --> MP[Mapper Proxy<br/>Mapper代理]
SS --> TX[Transaction<br/>事务]
E --> SH[StatementHandler]
SH --> PH[ParameterHandler]
SH --> RH[ResultSetHandler]
2.2 核心组件类图 #
classDiagram
class SqlSessionFactoryBuilder {
+build(InputStream) SqlSessionFactory
+build(Configuration) SqlSessionFactory
}
class SqlSessionFactory {
<<interface>>
+openSession() SqlSession
+getConfiguration() Configuration
}
class DefaultSqlSessionFactory {
-Configuration configuration
+openSession() SqlSession
}
class SqlSession {
<<interface>>
+selectOne(String, Object) T
+selectList(String, Object) List
+insert(String, Object) int
+update(String, Object) int
+delete(String, Object) int
+getMapper(Class) T
+commit() void
+rollback() void
+close() void
}
class DefaultSqlSession {
-Configuration configuration
-Executor executor
}
class Configuration {
-Environment environment
-MapperRegistry mapperRegistry
-Map~String, MappedStatement~ mappedStatements
-TypeHandlerRegistry typeHandlerRegistry
-InterceptorChain interceptorChain
}
SqlSessionFactoryBuilder ..> SqlSessionFactory : creates
SqlSessionFactory <|.. DefaultSqlSessionFactory
SqlSession <|.. DefaultSqlSession
DefaultSqlSessionFactory --> Configuration
DefaultSqlSession --> Configuration
DefaultSqlSession --> Executor
2.3 Executor 继承体系 #
classDiagram
class Executor {
<<interface>>
+update(MappedStatement, Object) int
+query(MappedStatement, Object, RowBounds, ResultHandler) List
+commit(boolean) void
+rollback(boolean) void
+createCacheKey() CacheKey
}
class BaseExecutor {
<<abstract>>
#Transaction transaction
#PerpetualCache localCache
#doUpdate()* int
#doQuery()* List
}
class SimpleExecutor {
+doQuery() List
+doUpdate() int
}
class ReuseExecutor {
-Map~String, Statement~ statementMap
+doQuery() List
}
class BatchExecutor {
-List~Statement~ statementList
+doUpdate() int
}
class CachingExecutor {
-Executor delegate
-TransactionalCacheManager tcm
+query() List
}
Executor <|.. BaseExecutor
Executor <|.. CachingExecutor
BaseExecutor <|-- SimpleExecutor
BaseExecutor <|-- ReuseExecutor
BaseExecutor <|-- BatchExecutor
CachingExecutor o-- Executor : 装饰
3. 初始化流程 #
3.1 初始化时序图 #
sequenceDiagram
autonumber
participant Client as 客户端
participant Builder as SqlSessionFactoryBuilder
participant XMLConfig as XMLConfigBuilder
participant Config as Configuration
participant XMLMapper as XMLMapperBuilder
Client->>Builder: build(inputStream)
Builder->>XMLConfig: new XMLConfigBuilder(inputStream)
XMLConfig->>Config: new Configuration()
Builder->>XMLConfig: parse()
activate XMLConfig
XMLConfig->>Config: 解析 properties
XMLConfig->>Config: 解析 settings
XMLConfig->>Config: 解析 typeAliases
XMLConfig->>Config: 解析 plugins
XMLConfig->>Config: 解析 environments
XMLConfig->>Config: 解析 typeHandlers
XMLConfig->>XMLMapper: 解析 mappers
XMLMapper->>Config: 注册 MappedStatement
XMLMapper->>Config: 注册 ResultMap
XMLMapper-->>XMLConfig: 完成
deactivate XMLConfig
XMLConfig-->>Builder: 返回 Configuration
Builder->>Builder: new DefaultSqlSessionFactory(config)
Builder-->>Client: 返回 SqlSessionFactory
3.2 配置文件解析流程 #
flowchart TB
A[mybatis-config.xml] --> B[XMLConfigBuilder]
B --> C{解析各节点}
C --> D[properties<br/>外部属性]
C --> E[settings<br/>全局设置]
C --> F[typeAliases<br/>类型别名]
C --> G[plugins<br/>插件]
C --> H[environments<br/>环境配置]
C --> I[typeHandlers<br/>类型处理器]
C --> J[mappers<br/>映射器]
J --> K{mapper配置方式}
K --> L[resource<br/>XML文件路径]
K --> M[class<br/>Mapper接口]
K --> N[package<br/>包扫描]
L --> O[XMLMapperBuilder]
M --> P[MapperAnnotationBuilder]
N --> P
O --> Q[解析Mapper.xml]
P --> R[解析注解]
Q --> S[MappedStatement]
R --> S
S --> T[Configuration]
3.3 MappedStatement 结构 #
classDiagram
class MappedStatement {
-String id
-SqlCommandType sqlCommandType
-SqlSource sqlSource
-ParameterMap parameterMap
-List~ResultMap~ resultMaps
-Cache cache
-boolean useCache
-boolean flushCacheRequired
-StatementType statementType
-Integer timeout
-Integer fetchSize
}
class SqlSource {
<<interface>>
+getBoundSql(Object) BoundSql
}
class StaticSqlSource {
-String sql
}
class DynamicSqlSource {
-SqlNode rootSqlNode
}
class RawSqlSource {
-SqlSource sqlSource
}
class BoundSql {
-String sql
-List~ParameterMapping~ parameterMappings
-Object parameterObject
-Map additionalParameters
}
MappedStatement --> SqlSource
SqlSource <|.. StaticSqlSource
SqlSource <|.. DynamicSqlSource
SqlSource <|.. RawSqlSource
SqlSource ..> BoundSql : creates
3.4 初始化源码解析 #
/**
* SqlSessionFactoryBuilder - 入口类
*/
public class SqlSessionFactoryBuilder {
public SqlSessionFactory build(InputStream inputStream) {
return build(inputStream, null, null);
}
public SqlSessionFactory build(InputStream inputStream,
String environment,
Properties properties) {
try {
// 1. 创建 XML 配置解析器
XMLConfigBuilder parser = new XMLConfigBuilder(
inputStream, environment, properties);
// 2. 解析配置文件，返回 Configuration 对象
Configuration config = parser.parse();
// 3. 创建 DefaultSqlSessionFactory
return build(config);
} catch (Exception e) {
throw ExceptionFactory.wrapException("Error building SqlSession.", e);
}
}
public SqlSessionFactory build(Configuration config) {
return new DefaultSqlSessionFactory(config);
}
}
/**
* XMLConfigBuilder - 解析 mybatis-config.xml
*/
public class XMLConfigBuilder extends BaseBuilder {
public Configuration parse() {
if (parsed) {
throw new BuilderException("Each XMLConfigBuilder can only be used once.");
}
parsed = true;
// 从根节点 <configuration> 开始解析
parseConfiguration(parser.evalNode("/configuration"));
return configuration;
}
private void parseConfiguration(XNode root) {
try {
// 按顺序解析各个子节点
propertiesElement(root.evalNode("properties"));
Properties settings = settingsAsProperties(root.evalNode("settings"));
typeAliasesElement(root.evalNode("typeAliases"));
pluginElement(root.evalNode("plugins"));
objectFactoryElement(root.evalNode("objectFactory"));
settingsElement(settings);
environmentsElement(root.evalNode("environments"));
typeHandlerElement(root.evalNode("typeHandlers"));
mapperElement(root.evalNode("mappers")); // ⭐ 解析 Mapper
} catch (Exception e) {
throw new BuilderException("Error parsing SQL Mapper Configuration.", e);
}
}
}
4. SQL 执行流程 #
4.1 SQL 执行时序图 #
sequenceDiagram
autonumber
participant Client as 客户端
participant SS as SqlSession
participant E as Executor
participant SH as StatementHandler
participant PH as ParameterHandler
participant TH as TypeHandler
participant RH as ResultSetHandler
participant DB as Database
Client->>SS: selectList(statementId, parameter)
SS->>SS: getMappedStatement(id)
SS->>E: query(ms, parameter, rowBounds, resultHandler)
alt 缓存命中
E->>E: 查询一级缓存
E-->>SS: 返回缓存结果
else 缓存未命中
E->>E: 创建 CacheKey
E->>SH: prepare(connection, timeout)
SH->>DB: prepareStatement(sql)
DB-->>SH: PreparedStatement
E->>SH: parameterize(statement)
SH->>PH: setParameters(ps)
loop 遍历参数映射
PH->>TH: setParameter(ps, i, value, jdbcType)
TH->>DB: ps.setXxx(i, value)
end
E->>SH: query(statement, resultHandler)
SH->>DB: ps.execute()
DB-->>SH: ResultSet
SH->>RH: handleResultSets(ps)
loop 遍历结果集
RH->>TH: getResult(rs, columnName)
TH-->>RH: Java对象
end
RH-->>SH: List<Object>
SH-->>E: List<Object>
E->>E: 放入一级缓存
end
E-->>SS: List<Object>
SS-->>Client: List<Object>
4.2 执行器工作流程 #
flowchart TB
A[SqlSession.selectList] --> B[获取 MappedStatement]
B --> C[Executor.query]
C --> D{二级缓存开启?}
D -->|是| E[CachingExecutor]
D -->|否| F[BaseExecutor]
E --> G{二级缓存命中?}
G -->|是| H[返回缓存结果]
G -->|否| F
F --> I{一级缓存命中?}
I -->|是| J[返回缓存结果]
I -->|否| K[queryFromDatabase]
K --> L[doQuery - 由子类实现]
L --> M{Executor类型}
M -->|SimpleExecutor| N[每次创建新Statement]
M -->|ReuseExecutor| O[复用Statement]
M -->|BatchExecutor| P[批量执行]
N --> Q[StatementHandler.prepare]
O --> Q
P --> Q
Q --> R[ParameterHandler.setParameters]
R --> S[StatementHandler.query]
S --> T[ResultSetHandler.handleResultSets]
T --> U[返回结果并缓存]
4.3 四大处理器协作 #
flowchart LR
subgraph Executor["Executor 执行器"]
E1[管理事务]
E2[管理缓存]
E3[创建Handler]
end
subgraph StatementHandler["StatementHandler"]
S1[prepare<br/>创建Statement]
S2[parameterize<br/>委托参数处理]
S3[query/update<br/>执行SQL]
end
subgraph ParameterHandler["ParameterHandler"]
P1[setParameters<br/>设置SQL参数]
end
subgraph ResultSetHandler["ResultSetHandler"]
R1[handleResultSets<br/>处理结果集]
R2[映射到Java对象]
end
subgraph TypeHandler["TypeHandler"]
T1[setParameter<br/>Java→JDBC]
T2[getResult<br/>JDBC→Java]
end
Executor --> StatementHandler
StatementHandler --> ParameterHandler
StatementHandler --> ResultSetHandler
ParameterHandler --> TypeHandler
ResultSetHandler --> TypeHandler
4.4 DefaultSqlSession 核心代码 #
/**
* DefaultSqlSession - SQL 执行入口
*/
public class DefaultSqlSession implements SqlSession {
private final Configuration configuration;
private final Executor executor;
@Override
public <E> List<E> selectList(String statement, Object parameter) {
return this.selectList(statement, parameter, RowBounds.DEFAULT);
}
@Override
public <E> List<E> selectList(String statement, Object parameter,
RowBounds rowBounds) {
try {
// 1. 获取 MappedStatement
MappedStatement ms = configuration.getMappedStatement(statement);
// 2. 调用 Executor 执行查询
return executor.query(ms, wrapCollection(parameter),
rowBounds, Executor.NO_RESULT_HANDLER);
} catch (Exception e) {
throw ExceptionFactory.wrapException("Error querying database.", e);
}
}
@Override
public int update(String statement, Object parameter) {
try {
dirty = true;
MappedStatement ms = configuration.getMappedStatement(statement);
return executor.update(ms, wrapCollection(parameter));
} catch (Exception e) {
throw ExceptionFactory.wrapException("Error updating database.", e);
}
}
@Override
public <T> T getMapper(Class<T> type) {
return configuration.getMapper(type, this);
}
}
4.5 SimpleExecutor 执行逻辑 #
/**
* SimpleExecutor - 简单执行器
*/
public class SimpleExecutor extends BaseExecutor {
@Override
public <E> List<E> doQuery(MappedStatement ms, Object parameter,
RowBounds rowBounds, ResultHandler resultHandler,
BoundSql boundSql) throws SQLException {
Statement stmt = null;
try {
Configuration configuration = ms.getConfiguration();
// 1. 创建 StatementHandler
StatementHandler handler = configuration.newStatementHandler(
wrapper, ms, parameter, rowBounds, resultHandler, boundSql);
// 2. 预处理 Statement
stmt = prepareStatement(handler, ms.getStatementLog());
// 3. 执行查询
return handler.query(stmt, resultHandler);
} finally {
closeStatement(stmt);
}
}
private Statement prepareStatement(StatementHandler handler, Log statementLog)
throws SQLException {
Statement stmt;
// 1. 获取数据库连接
Connection connection = getConnection(statementLog);
// 2. 创建 Statement
stmt = handler.prepare(connection, transaction.getTimeout());
// 3. 设置参数
handler.parameterize(stmt);
return stmt;
}
}
5. 动态代理机制 #
5.1 Mapper 代理原理图 #
flowchart TB
subgraph Application["应用层"]
A[UserMapper<br/>接口定义]
B["mapper.selectById(1)"]
end
subgraph Proxy["代理层"]
C[MapperProxyFactory<br/>创建代理]
D[MapperProxy<br/>InvocationHandler]
E[MapperMethod<br/>方法执行器]
end
subgraph SqlSession["SqlSession层"]
F[selectOne]
G[selectList]
H[insert]
I[update]
J[delete]
end
A -->|getMapper| C
C -->|Proxy.newProxyInstance| D
B -->|invoke| D
D -->|cachedInvoker| E
E -->|SELECT| F
E -->|SELECT returnMany| G
E -->|INSERT| H
E -->|UPDATE| I
E -->|DELETE| J
5.2 动态代理时序图 #
sequenceDiagram
autonumber
participant Client as 客户端
participant SS as SqlSession
participant MR as MapperRegistry
participant MPF as MapperProxyFactory
participant MP as MapperProxy
participant MM as MapperMethod
Client->>SS: getMapper(UserMapper.class)
SS->>MR: getMapper(type, sqlSession)
MR->>MPF: newInstance(sqlSession)
Note over MPF: 创建 MapperProxy
MPF->>MP: new MapperProxy(sqlSession, mapperInterface, methodCache)
Note over MPF: JDK动态代理
MPF->>MPF: Proxy.newProxyInstance(classLoader, interfaces, mapperProxy)
MPF-->>Client: 返回代理对象
Client->>MP: selectById(1)
MP->>MP: invoke(proxy, method, args)
alt Object方法
MP->>MP: method.invoke(this, args)
else 接口默认方法
MP->>MP: invokeDefaultMethod()
else 普通方法
MP->>MP: cachedInvoker(method)
MP->>MM: new MapperMethod(interface, method, config)
MP->>MM: execute(sqlSession, args)
MM->>MM: 判断SQL类型
MM->>SS: selectOne/selectList/insert/update/delete
SS-->>MM: 结果
MM-->>MP: 结果
end
MP-->>Client: 结果
5.3 MapperProxy 类结构 #
classDiagram
class MapperProxy~T~ {
-SqlSession sqlSession
-Class~T~ mapperInterface
-Map~Method, MapperMethodInvoker~ methodCache
+invoke(Object proxy, Method method, Object[] args) Object
-cachedInvoker(Method method) MapperMethodInvoker
}
class MapperProxyFactory~T~ {
-Class~T~ mapperInterface
-Map~Method, MapperMethodInvoker~ methodCache
+newInstance(SqlSession sqlSession) T
#newInstance(MapperProxy~T~ mapperProxy) T
}
class MapperMethod {
-SqlCommand command
-MethodSignature method
+execute(SqlSession sqlSession, Object[] args) Object
}
class SqlCommand {
-String name
-SqlCommandType type
}
class MethodSignature {
-boolean returnsMany
-boolean returnsMap
-boolean returnsVoid
-Class~?~ returnType
-ParamNameResolver paramNameResolver
}
class MapperMethodInvoker {
<<interface>>
+invoke(Object, Method, Object[], SqlSession) Object
}
class PlainMethodInvoker {
-MapperMethod mapperMethod
}
MapperProxyFactory ..> MapperProxy : creates
MapperProxy ..|> InvocationHandler
MapperProxy --> MapperMethodInvoker
MapperMethodInvoker <|.. PlainMethodInvoker
PlainMethodInvoker --> MapperMethod
MapperMethod --> SqlCommand
MapperMethod --> MethodSignature
5.4 MapperProxy 源码解析 #
/**
* MapperProxy - Mapper 接口的代理处理器
*/
public class MapperProxy<T> implements InvocationHandler, Serializable {
private final SqlSession sqlSession;
private final Class<T> mapperInterface;
private final Map<Method, MapperMethodInvoker> methodCache;
/**
* 代理方法调用入口
*/
@Override
public Object invoke(Object proxy, Method method, Object[] args)
throws Throwable {
try {
// 1. 如果是 Object 类的方法，直接调用
if (Object.class.equals(method.getDeclaringClass())) {
return method.invoke(this, args);
}
// 2. 如果是接口的默认方法（Java 8+）
if (method.isDefault()) {
return invokeDefaultMethod(proxy, method, args);
}
} catch (Throwable t) {
throw ExceptionUtil.unwrapThrowable(t);
}
// 3. 获取或创建 MapperMethodInvoker，然后执行
final MapperMethodInvoker invoker = cachedInvoker(method);
return invoker.invoke(proxy, method, args, sqlSession);
}
/**
* 缓存方法调用器
*/
private MapperMethodInvoker cachedInvoker(Method method) throws Throwable {
return methodCache.computeIfAbsent(method, m -> {
if (m.isDefault()) {
return new DefaultMethodInvoker(getMethodHandle(method));
} else {
return new PlainMethodInvoker(
new MapperMethod(mapperInterface, method,
sqlSession.getConfiguration()));
}
});
}
}
/**
* MapperMethod - 封装方法执行逻辑
*/
public class MapperMethod {
private final SqlCommand command;
private final MethodSignature method;
/**
* 执行方法
*/
public Object execute(SqlSession sqlSession, Object[] args) {
Object result;
switch (command.getType()) {
case INSERT: {
Object param = method.convertArgsToSqlCommandParam(args);
result = rowCountResult(sqlSession.insert(command.getName(), param));
break;
}
case UPDATE: {
Object param = method.convertArgsToSqlCommandParam(args);
result = rowCountResult(sqlSession.update(command.getName(), param));
break;
}
case DELETE: {
Object param = method.convertArgsToSqlCommandParam(args);
result = rowCountResult(sqlSession.delete(command.getName(), param));
break;
}
case SELECT:
if (method.returnsVoid() && method.hasResultHandler()) {
executeWithResultHandler(sqlSession, args);
result = null;
} else if (method.returnsMany()) {
result = executeForMany(sqlSession, args);
} else if (method.returnsMap()) {
result = executeForMap(sqlSession, args);
} else {
Object param = method.convertArgsToSqlCommandParam(args);
result = sqlSession.selectOne(command.getName(), param);
}
break;
default:
throw new BindingException("Unknown execution method for: "
+ command.getName());
}
return result;
}
}
6. 缓存机制 #
6.1 两级缓存架构 #
flowchart TB
subgraph Session1["SqlSession 1"]
L1A[一级缓存<br/>PerpetualCache]
end
subgraph Session2["SqlSession 2"]
L1B[一级缓存<br/>PerpetualCache]
end
subgraph Session3["SqlSession 3"]
L1C[一级缓存<br/>PerpetualCache]
end
subgraph L2Cache["二级缓存 (Mapper Namespace级别)"]
subgraph NS1["UserMapper Namespace"]
C1[SynchronizedCache]
C2[LoggingCache]
C3[SerializedCache]
C4[LruCache]
C5[PerpetualCache]
C1 --> C2 --> C3 --> C4 --> C5
end
subgraph NS2["OrderMapper Namespace"]
D1[SynchronizedCache]
D2[LoggingCache]
D3[PerpetualCache]
D1 --> D2 --> D3
end
end
Session1 --> L2Cache
Session2 --> L2Cache
Session3 --> L2Cache
L2Cache --> DB[(Database)]
style L1A fill:#e1f5fe
style L1B fill:#e1f5fe
style L1C fill:#e1f5fe
style L2Cache fill:#fff3e0
6.2 缓存查询流程 #
flowchart TB
A[查询请求] --> B{二级缓存开启?}
B -->|是| C[CachingExecutor]
B -->|否| D[BaseExecutor]
C --> E{二级缓存命中?}
E -->|是| F[返回二级缓存结果]
E -->|否| D
D --> G{一级缓存命中?}
G -->|是| H[返回一级缓存结果]
G -->|否| I[查询数据库]
I --> J[结果放入一级缓存]
J --> K{二级缓存开启?}
K -->|是| L[暂存到TransactionalCache]
K -->|否| M[返回结果]
L --> N{事务提交?}
N -->|是| O[刷新到二级缓存]
N -->|否| P[事务回滚清空]
O --> M
P --> M
6.3 缓存装饰器模式 #
classDiagram
class Cache {
<<interface>>
+getId() String
+putObject(Object key, Object value) void
+getObject(Object key) Object
+removeObject(Object key) Object
+clear() void
+getSize() int
}
class PerpetualCache {
-String id
-Map~Object, Object~ cache
+putObject() void
+getObject() Object
}
class LruCache {
-Cache delegate
-Map keyMap
-Object eldestKey
}
class FifoCache {
-Cache delegate
-Deque~Object~ keyList
}
class SoftCache {
-Cache delegate
-Deque~Object~ hardLinksToAvoidGC
}
class WeakCache {
-Cache delegate
}
class SynchronizedCache {
-Cache delegate
}
class LoggingCache {
-Cache delegate
-int requests
-int hits
}
class SerializedCache {
-Cache delegate
}
class ScheduledCache {
-Cache delegate
-long clearInterval
}
Cache <|.. PerpetualCache
Cache <|.. LruCache
Cache <|.. FifoCache
Cache <|.. SoftCache
Cache <|.. WeakCache
Cache <|.. SynchronizedCache
Cache <|.. LoggingCache
Cache <|.. SerializedCache
Cache <|.. ScheduledCache
LruCache o-- Cache
FifoCache o-- Cache
SoftCache o-- Cache
WeakCache o-- Cache
SynchronizedCache o-- Cache
LoggingCache o-- Cache
SerializedCache o-- Cache
ScheduledCache o-- Cache
6.4 一级缓存实现 #
/**
* 一级缓存 - BaseExecutor 中的实现
*/
public abstract class BaseExecutor implements Executor {
// 一级缓存
protected PerpetualCache localCache;
@Override
public <E> List<E> query(MappedStatement ms, Object parameter,
RowBounds rowBounds, ResultHandler resultHandler,
CacheKey key, BoundSql boundSql) throws SQLException {
// 如果配置了 flushCache=true，清空缓存
if (queryStack == 0 && ms.isFlushCacheRequired()) {
clearLocalCache();
}
List<E> list;
try {
queryStack++;
// 从一级缓存获取结果
list = resultHandler == null
? (List<E>) localCache.getObject(key)
: null;
if (list != null) {
// 缓存命中
handleLocallyCachedOutputParameters(ms, key, parameter, boundSql);
} else {
// 缓存未命中，查询数据库
list = queryFromDatabase(ms, parameter, rowBounds,
resultHandler, key, boundSql);
}
} finally {
queryStack--;
}
return list;
}
/**
* 创建缓存 Key
*/
@Override
public CacheKey createCacheKey(MappedStatement ms, Object parameterObject,
RowBounds rowBounds, BoundSql boundSql) {
CacheKey cacheKey = new CacheKey();
// 缓存 Key 由以下几部分组成
cacheKey.update(ms.getId()); // Statement ID
cacheKey.update(rowBounds.getOffset()); // 分页偏移
cacheKey.update(rowBounds.getLimit()); // 分页大小
cacheKey.update(boundSql.getSql()); // SQL 语句
// 参数值
List<ParameterMapping> parameterMappings = boundSql.getParameterMappings();
for (ParameterMapping pm : parameterMappings) {
if (pm.getMode() != ParameterMode.OUT) {
Object value = /* 获取参数值 */;
cacheKey.update(value);
}
}
return cacheKey;
}
}
6.5 二级缓存实现 #
/**
* 二级缓存 - CachingExecutor (装饰器模式)
*/
public class CachingExecutor implements Executor {
private final Executor delegate; // 被装饰的执行器
private final TransactionalCacheManager tcm = new TransactionalCacheManager();
@Override
public <E> List<E> query(MappedStatement ms, Object parameterObject,
RowBounds rowBounds, ResultHandler resultHandler,
CacheKey key, BoundSql boundSql) throws SQLException {
// 获取 MappedStatement 对应的二级缓存
Cache cache = ms.getCache();
if (cache != null) {
flushCacheIfRequired(ms);
if (ms.isUseCache() && resultHandler == null) {
// 从二级缓存获取结果
List<E> list = (List<E>) tcm.getObject(cache, key);
if (list == null) {
// 二级缓存未命中，查询一级缓存/数据库
list = delegate.query(ms, parameterObject, rowBounds,
resultHandler, key, boundSql);
// 将结果放入二级缓存（暂存）
tcm.putObject(cache, key, list);
}
return list;
}
}
return delegate.query(ms, parameterObject, rowBounds,
resultHandler, key, boundSql);
}
@Override
public void commit(boolean required) throws SQLException {
delegate.commit(required);
tcm.commit(); // 提交时才真正写入二级缓存
}
@Override
public void rollback(boolean required) throws SQLException {
try {
delegate.rollback(required);
} finally {
if (required) {
tcm.rollback(); // 回滚时清空暂存区
}
}
}
}
6.6 缓存配置示例 #
<!-- 开启二级缓存 -->
<mapper namespace="com.example.mapper.UserMapper">
<!-- 配置二级缓存 -->
<cache
eviction="LRU"
flushInterval="60000"
size="1024"
readOnly="false"/>
<!--
eviction: 淘汰策略 (LRU/FIFO/SOFT/WEAK)
flushInterval: 刷新间隔（毫秒）
size: 缓存数量
readOnly: 只读（true返回相同实例，false返回拷贝）
-->
<select id="selectById" resultType="User" useCache="true">
SELECT * FROM user WHERE id = #{id}
</select>
<update id="updateById" flushCache="true">
UPDATE user SET name = #{name} WHERE id = #{id}
</update>
</mapper>
7. 插件机制 #
7.1 插件原理 #
flowchart TB
subgraph Interceptable["可拦截的四大对象"]
E[Executor<br/>执行器]
SH[StatementHandler<br/>语句处理器]
PH[ParameterHandler<br/>参数处理器]
RH[ResultSetHandler<br/>结果集处理器]
end
subgraph InterceptMethods["可拦截方法"]
E1[update, query, commit<br/>rollback, flushStatements...]
SH1[prepare, parameterize<br/>batch, update, query]
PH1[getParameterObject<br/>setParameters]
RH1[handleResultSets<br/>handleOutputParameters]
end
E --- E1
SH --- SH1
PH --- PH1
RH --- RH1
subgraph Plugin["插件机制"]
P1[Interceptor 接口]
P2[Plugin 代理工具]
P3[InterceptorChain 责任链]
end
Plugin --> Interceptable
7.2 插件执行流程 #
sequenceDiagram
autonumber
participant Config as Configuration
participant Chain as InterceptorChain
participant Plugin as Plugin
participant Interceptor as 自定义Interceptor
participant Target as 目标对象
Config->>Config: newExecutor()
Config->>Chain: pluginAll(executor)
loop 遍历所有拦截器
Chain->>Interceptor: plugin(target)
Interceptor->>Plugin: wrap(target, this)
Plugin->>Plugin: 解析@Intercepts注解
Plugin->>Plugin: 获取签名方法
alt 需要代理
Plugin->>Plugin: Proxy.newProxyInstance()
Plugin-->>Interceptor: 代理对象
else 不需要代理
Plugin-->>Interceptor: 原对象
end
Interceptor-->>Chain: 代理/原对象
end
Chain-->>Config: 最终代理对象
Note over Config,Target: 方法调用时
Config->>Plugin: invoke(proxy, method, args)
alt 方法需要拦截
Plugin->>Interceptor: intercept(Invocation)
Interceptor->>Interceptor: 前置处理
Interceptor->>Target: invocation.proceed()
Target-->>Interceptor: 结果
Interceptor->>Interceptor: 后置处理
Interceptor-->>Plugin: 结果
else 方法不需要拦截
Plugin->>Target: method.invoke(target, args)
Target-->>Plugin: 结果
end
Plugin-->>Config: 结果
7.3 插件类结构 #
classDiagram
class Interceptor {
<<interface>>
+intercept(Invocation invocation) Object
+plugin(Object target) Object
+setProperties(Properties properties) void
}
class Plugin {
-Object target
-Interceptor interceptor
-Map~Class, Set~Method~~ signatureMap
+wrap(Object target, Interceptor interceptor)$ Object
+invoke(Object proxy, Method method, Object[] args) Object
}
class Invocation {
-Object target
-Method method
-Object[] args
+proceed() Object
+getTarget() Object
+getMethod() Method
+getArgs() Object[]
}
class InterceptorChain {
-List~Interceptor~ interceptors
+pluginAll(Object target) Object
+addInterceptor(Interceptor interceptor) void
}
class Intercepts {
<<annotation>>
+value() Signature[]
}
class Signature {
<<annotation>>
+type() Class
+method() String
+args() Class[]
}
Interceptor ..> Plugin : 使用
Plugin ..> Invocation : 创建
InterceptorChain o-- Interceptor
Interceptor ..> Intercepts : 标注
Intercepts *-- Signature
7.4 自定义插件示例 #
/**
* SQL 执行时间统计插件
*/
@Intercepts({
@Signature(
type = Executor.class,
method = "query",
args = {MappedStatement.class, Object.class,
RowBounds.class, ResultHandler.class}
),
@Signature(
type = Executor.class,
method = "update",
args = {MappedStatement.class, Object.class}
)
})
public class SqlExecutionTimePlugin implements Interceptor {
private static final Logger log = LoggerFactory.getLogger(
SqlExecutionTimePlugin.class);
private long slowSqlThreshold = 1000; // 慢 SQL 阈值（毫秒）
@Override
public Object intercept(Invocation invocation) throws Throwable {
// 1. 获取执行信息
MappedStatement ms = (MappedStatement) invocation.getArgs()[0];
String sqlId = ms.getId();
// 2. 记录开始时间
long startTime = System.currentTimeMillis();
try {
// 3. 执行原方法
return invocation.proceed();
} finally {
// 4. 计算执行时间
long executionTime = System.currentTimeMillis() - startTime;
// 5. 慢 SQL 告警
if (executionTime > slowSqlThreshold) {
log.warn("慢SQL告警 - ID: {}, 耗时: {}ms", sqlId, executionTime);
} else {
log.debug("SQL执行 - ID: {}, 耗时: {}ms", sqlId, executionTime);
}
}
}
@Override
public Object plugin(Object target) {
// 只代理 Executor
if (target instanceof Executor) {
return Plugin.wrap(target, this);
}
return target;
}
@Override
public void setProperties(Properties properties) {
String threshold = properties.getProperty("slowSqlThreshold");
if (threshold != null) {
this.slowSqlThreshold = Long.parseLong(threshold);
}
}
}
/**
* 分页插件示例
*/
@Intercepts({
@Signature(
type = StatementHandler.class,
method = "prepare",
args = {Connection.class, Integer.class}
)
})
public class PaginationPlugin implements Interceptor {
@Override
public Object intercept(Invocation invocation) throws Throwable {
StatementHandler statementHandler = (StatementHandler) invocation.getTarget();
// 使用 MetaObject 操作对象属性
MetaObject metaObject = SystemMetaObject.forObject(statementHandler);
// 获取原始 SQL
String sql = (String) metaObject.getValue("delegate.boundSql.sql");
// 获取参数对象
Object parameterObject = metaObject.getValue("delegate.boundSql.parameterObject");
// 判断是否需要分页
if (parameterObject instanceof PageParam) {
PageParam page = (PageParam) parameterObject;
// 修改 SQL
String pageSql = sql + " LIMIT " + page.getOffset()
+ ", " + page.getPageSize();
metaObject.setValue("delegate.boundSql.sql", pageSql);
}
return invocation.proceed();
}
}
7.5 Plugin 核心源码 #
/**
* Plugin - 创建代理对象的工具类
*/
public class Plugin implements InvocationHandler {
private final Object target;
private final Interceptor interceptor;
private final Map<Class<?>, Set<Method>> signatureMap;
/**
* 包装目标对象
*/
public static Object wrap(Object target, Interceptor interceptor) {
// 1. 获取拦截器的签名信息
Map<Class<?>, Set<Method>> signatureMap = getSignatureMap(interceptor);
// 2. 获取目标对象的类型
Class<?> type = target.getClass();
// 3. 获取目标对象需要被代理的接口
Class<?>[] interfaces = getAllInterfaces(type, signatureMap);
// 4. 如果有需要代理的接口，创建代理对象
if (interfaces.length > 0) {
return Proxy.newProxyInstance(
type.getClassLoader(),
interfaces,
new Plugin(target, interceptor, signatureMap));
}
return target;
}
/**
* 代理方法调用
*/
@Override
public Object invoke(Object proxy, Method method, Object[] args)
throws Throwable {
try {
// 获取当前接口的可拦截方法
Set<Method> methods = signatureMap.get(method.getDeclaringClass());
// 如果当前方法需要被拦截
if (methods != null && methods.contains(method)) {
// 调用拦截器的 intercept 方法
return interceptor.intercept(new Invocation(target, method, args));
}
// 不需要拦截，直接调用原方法
return method.invoke(target, args);
} catch (Exception e) {
throw ExceptionUtil.unwrapThrowable(e);
}
}
/**
* 解析 @Intercepts 注解获取签名信息
*/
private static Map<Class<?>, Set<Method>> getSignatureMap(Interceptor interceptor) {
Intercepts interceptsAnnotation = interceptor.getClass()
.getAnnotation(Intercepts.class);
if (interceptsAnnotation == null) {
throw new PluginException("No @Intercepts annotation was found");
}
Signature[] sigs = interceptsAnnotation.value();
Map<Class<?>, Set<Method>> signatureMap = new HashMap<>();
for (Signature sig : sigs) {
Set<Method> methods = signatureMap.computeIfAbsent(
sig.type(), k -> new HashSet<>());
Method method = sig.type().getMethod(sig.method(), sig.args());
methods.add(method);
}
return signatureMap;
}
}
8. 总结 #
8.1 MyBatis 完整执行流程 #
flowchart TB
subgraph Init["1. 初始化阶段"]
A1[mybatis-config.xml] --> A2[XMLConfigBuilder]
A2 --> A3[Configuration]
A4[Mapper.xml] --> A5[XMLMapperBuilder]
A5 --> A6[MappedStatement]
A6 --> A3
A3 --> A7[SqlSessionFactory]
end
subgraph Execute["2. 执行阶段"]
B1[调用Mapper方法] --> B2[MapperProxy<br/>JDK动态代理]
B2 --> B3[MapperMethod]
B3 --> B4[SqlSession<br/>selectOne/insert...]
B4 --> B5[Executor<br/>执行器]
B5 --> B6{缓存}
B6 -->|命中| B7[返回结果]
B6 -->|未命中| B8[StatementHandler]
B8 --> B9[ParameterHandler<br/>设置参数]
B9 --> B10[TypeHandler<br/>类型转换]
B10 --> B11[(Database)]
B11 --> B12[ResultSetHandler<br/>结果映射]
B12 --> B13[TypeHandler<br/>类型转换]
B13 --> B7
end
Init --> Execute
8.2 核心设计模式 #
mindmap
root((MyBatis<br/>设计模式))
创建型
工厂模式
SqlSessionFactory
MapperProxyFactory
建造者模式
SqlSessionFactoryBuilder
XMLConfigBuilder
单例模式
Configuration
ErrorContext
结构型
代理模式
MapperProxy
Plugin
装饰器模式
Cache装饰器
CachingExecutor
组合模式
SqlNode树
ResultMap
行为型
模板方法
BaseExecutor
BaseTypeHandler
策略模式
Executor类型
StatementHandler类型
责任链模式
插件机制
InterceptorChain
迭代器模式
PropertyTokenizer
8.3 核心组件职责 #
| 组件 | 职责 | 生命周期 |
|---|---|---|
| SqlSessionFactoryBuilder | 解析配置，创建工厂 | 用后即弃 |
| SqlSessionFactory | 创建 SqlSession | 应用级单例 |
| SqlSession | 执行SQL，获取Mapper | 请求级别 |
| Executor | 管理缓存，执行SQL | 请求级别 |
| StatementHandler | 操作Statement | 单次执行 |
| ParameterHandler | 设置SQL参数 | 单次执行 |
| ResultSetHandler | 处理结果集 | 单次执行 |
| TypeHandler | Java/JDBC类型转换 | 应用级别 |
8.4 缓存对比 #
flowchart LR
subgraph L1["一级缓存"]
direction TB
L1A[作用域: SqlSession]
L1B[默认开启]
L1C[无法关闭]
L1D[事务内有效]
L1E[HashMap存储]
end
subgraph L2["二级缓存"]
direction TB
L2A[作用域: Mapper Namespace]
L2B[默认关闭]
L2C[需手动开启]
L2D[跨Session有效]
L2E[装饰器链存储]
end
L1 -.-> L2
8.5 关键要点 #
/**
* MyBatis 核心要点总结
*/
public class MyBatisSummary {
/*
* ⭐ 初始化
* 1. 解析 XML 配置文件 → Configuration
* 2. 解析 Mapper.xml → MappedStatement
* 3. 注册 Mapper 接口 → MapperRegistry
* 4. 创建 SqlSessionFactory
*
* ⭐ Mapper 代理
* 1. getMapper() → MapperProxyFactory.newInstance()
* 2. JDK 动态代理创建代理对象
* 3. 方法调用 → MapperProxy.invoke()
* 4. 解析方法类型 → 调用 SqlSession 对应方法
*
* ⭐ SQL 执行
* 1. Executor: 执行入口，管理缓存
* 2. StatementHandler: 操作 JDBC Statement
* 3. ParameterHandler: 设置 SQL 参数
* 4. ResultSetHandler: 处理查询结果
* 5. TypeHandler: Java ↔ JDBC 类型转换
*
* ⭐ 缓存机制
* 1. 一级缓存: SqlSession 级别，默认开启
* 2. 二级缓存: Mapper 级别，需要手动开启
* 3. 装饰器模式: 灵活组合缓存功能
* 4. 事务缓存: 保证数据一致性
*
* ⭐ 插件机制
* 1. 基于 JDK 动态代理实现
* 2. 可拦截: Executor, StatementHandler,
* ParameterHandler, ResultSetHandler
* 3. 责任链模式处理多个插件
* 4. 使用 @Intercepts + @Signature 声明拦截点
*/
}
